5" x 2" Rigid Caster | Phenolic Wheel | 1,000 Lbs Capacity
Introducing our Medium Duty '9' Series Rigid Casters, renowned for their robust construction and versatility across various industries. Our product is a bestseller, recognized for its excellent quality, functionality, and value. Enjoy the benefits of our swift delivery and competitive prices.
Technical Specifications:
| Wheel Material | Phenolic |
|---|---|
| Wheel Diameter | 5 inches |
| Wheel Tread Width | 2 inches |
| Load Capacity | 1,000 lbs each |
| Top Plate Size | 4" x 4-1/2" |
| Bolt Hole Spacing | 2-5/8" x 3-5/8" (Slotted to 3" x 3") |
| Wheel Durometer | 90 SHORE D (±5) |
| Mounting Bolt Size | 3/8 inch |
| Overall Height | 6-1/2 inches |
| Bearing Type | Roller Bearing (Other Options Available) |
| Wheel Color | Black |
| Temperature Range | -50°F – 250°F |
| Caster Bracket Material | Zinc Plated Steel |
| Grease Zerk | Yes |
| Axle | Zerk Axle |
Key Features:
- Industry Favorite: Preferred in industrial, warehousing, hospitality, institutional, and food service sectors.
- Heavy-Duty Construction: Crafted from 1/4" thick cold rolled steel for maximum durability.
- Exceptional Mobility: Designed, formed, and welded to withstand medium-duty applications.
- Versatile Utility: Ideal for carts, trucks, dollies, racks, and a wide range of equipment.
- Flexible Design Options: Available in rivet kingpin and kingpinless models.
- Robust Wheel Composition: Phenolic material offers high load-bearing capacity.
- OEM Preferred Series: Trusted by Original Equipment Manufacturers.
- NSF Listed: Majority of this series and wheels meet NSF standards.
- RoHS Compliant: Adheres to strict hazardous substances regulations.
- Grease Fitting in Raceway & Axle: Simplifies maintenance, enhancing longevity.
- Zinc Plated: Provides rust and corrosion resistance, increasing durability.
- Strong as Steel Phenolic Wheel: Combines strength and non-marking properties.
- High Resistance to Chemicals: Suitable for challenging environments.
Applications:
Suitable for a multitude of medium-duty environments. Perfect for equipment in industrial, warehousing, hospitality, institutional, and food processing settings, as well as retail displays and other applications.
Product Code: HQ2050R-PL1-PHR
